CNC Milling Machine 9015 Wood Router Italy Woodworking Machine
Product Description
Cnc Milling Machine 9015 Wood Router Italy Woodworking Machine
| CNC Milling Machine 9015 Wood Router Italy Woodworking Machine | ||||
| Description | Parameter | |||
| Model | AN9012 | AN9015 | AN1212 | AN-Customize |
| Working area(X*Y*Z) | 900*1200*200mm | 900*1500*200mm | 1200*1200*200mm | Customize |
| Table Surface | T-slot Table /Vaccum&T-slot Table | |||
| Frame | Heavy-duty industrial class squire tibe strong structure | |||
| X,Y Structure | Rack and Pinion Drive ,Taiwan PMI linear guide rails | |||
| Z Structure | Taiwan TBI Ball Screw | |||
| Spindle Power | 3KW/4.5KW/5.5KW/6LW/7.5KW/9KW-ATC | |||
| VFD Power | 3.7kw/5.5kw/7.5kw/11kw | |||
| Operating System | DSP control system/NC Studio control system/Mach 3 control system | |||
| Drive Motors | Leadshine drive and FL118stepper motors | |||
| Max Rapid Travel Rate | 33000mm/min | |||
| Max.Working Speed | 23000mm/min | |||
| Cutting accuracy | 0.03/1000mm | |||
| Worling Voltage | AC380v,50hZ,3ph(Option:220V) | |||
| Command Language | G code | |||
| Sostware Compatibility | Artcan/Power mill/Type3/Ucancam | |||
Application of Cnc Router wood :
1.Mould: wood,wax, wood, gypsum,foams,wax 1325 CNC Router Wood Working Machine wood machine
2. Furniture: wooden doors, cabinets, plate, office and wood furniture, tables, chair, doors and windows.
3. The wood products: voice box, game cabinets, computer tables, sewing machines table,instruments.
4.Plate processing: insulation part, plastic chemical components, PCB, inner body of car, bowling tracks, stairs, anti bate board, epoxy resin, ABS, PP, PE and other carbon mixed compounds.
5. Decorate industry: Acrylic, PVC, MDF, artificial stone, organic glass, plastic and soft metals such as copper engraving and milling process.
Standard Package: 1. Inner package: Covered with plastic film on the cnc machine.
2. Outside package: Standard marine export plywood case.
We can package according to your requests.
Delivery Detail: Shipped within 12 working days after payment.
1.24 months quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge if there is any problem during the warranty period.
2. Lifetime maintenance free of charge.
3. Free training course at our plant.
4. We will provide the consumable parts at an agency price when you need replacement.
5. 24 hours on line service each day, free technical support.
6. Machine has been adjusted before delivery.
7. Our staff can be sent to your company to install or adjust if necessary.
Product Categories : Anben CNC router > AN 1325 CNC router
