Wood Router Cutting Machines 1530 Machine Tool Spindle

Product Description

Product Description
Wood Router Cutting Machines 1530 Machine Tool Spindle
            Wood Router Cutting Machines 1530 Machine Tool SpindleWood Router Cutting Machines 1530 Machine Tool SpindleWood Router Cutting Machines 1530 Machine Tool SpindleWood Router Cutting Machines 1530 Machine Tool Spindle


Cnc Wood Router is also called Cnc Engraving Machine in the CNC machine industry. It refers to the ability of the CNC machine to perform movement about three different axis like X, Y, Z axis simultaneously. This type of wood CNC machine is designed and typeset by special engraving software, and the design and typesetting information is automatically transferred to the controller by the computer, and the controller controls the Engraving Machine to generate the X, Y, and Z axis engraving paths to complete processing of the materials fixed on the working table, so as to realize the various processing requirements of users.


With the features of low cost, simple operation and easy maintenance, this CNC wood router is considered an entry-level machine in the CNC machine industry and favored by users at home and abroad. The CNC wood router mainly performs some plane processing on the board. If you are just doing flat machining on some plates, this three-axis engraving machine is definitely your ideal choice.


Of course, if you have other machining requirements such as three-dimensional work pieces, curved surface machining of complex work pieces, we also have CNC equipment such as 4-axis CNC machine, rotary axis CNC machine, ATC CNC machine and multi-head engraving machine for you to choose.


Specification
     Wood Router Cutting Machines 1530 Machine Tool Spindle

Description

Parameter

Model

AN1325

AN1530

AN2030

AN-Customize

Working area(X*Y*Z)

1300*2500*200mm

1500*3000*200mm

2000*3000*200mm

Customize

Table Surface

T-slot Table  /  Vacuum & T-slot Table

Frame

Heavy-duty Industrial class square tube strong structure

X, Y Structure

Rack and Pinion Drive, Taiwan PMI linear guide rails

Z Structure

Taiwan TBI Ball Screw

Spindle Power

3KW / 4.5KW / 5.5KW / 6KW / 7.5KW / 9KW-ATC

VFD Power

3.7KW / 5.5KW / 7.5KW / 11KW

Operating System

DSP control system / Nc Studio control system

Drive Motors

Leadshine drive and FL118 stepper motors

Max. Rapid Travel Rate

33000mm/min

Max. Working Speed

23000mm/min

Cutting accuracy

±0.03/1000mm

Working Voltage

AC380V, 50Hz, 3PH (Option: 220V)

Command Language

G Code

Software Compatibility

Artcam / Power mill / Type 3 / Ucancam


More reasons for why choose us!
Wood Router Cutting Machines 1530 Machine Tool Spindle

Application



Wood Router Cutting Machines 1530 Machine Tool Spindle



Application&Sample



Wood Router Cutting Machines 1530 Machine Tool SpindleApplication of Cnc Router wood :

1.Mould: wood,wax, wood, gypsum,foams,wax   1325 CNC Router   Wood Working Machine  wood machine

2. Furniture: wooden doors, cabinets, plate, office and wood furniture, tables, chair, doors and windows.

3. The wood products: voice box, game cabinets, computer tables, sewing machines table,instruments.
4.Plate processing: insulation part, plastic chemical components, PCB, inner body of car, bowling tracks, stairs, anti bate board, epoxy resin, ABS, PP, PE and other carbon mixed compounds.
5. Decorate industry: Acrylic, PVC, MDF, artificial stone, organic glass, plastic and soft metals such as copper engraving and milling process.

Packaging & Shipping

Standard Package: 1. Inner package: Covered with plastic film on the cnc machine.

                                2. Outside package: Standard marine export plywood case.

                                We can package according to your requests.
Delivery Detail: Shipped within 12 working days after payment.

 Wood Router Cutting Machines 1530 Machine Tool Spindle

Our Services

1.24 months quality garantly,the machine with main parts(excluding the consumables)shall be changed free of charge if there is problem during  the warranty period.

2.Lifetime maintenance free of charge.

3.Free training course at our plant.

4.We will provide the consumable parts at an agency price when you need replacement.

5.24hours on line service each day,free technical support.

6.Machine has been adjusted before delivery.

7.Our staff can be sent to yuur company to install or adjust if necessary.

Company Information

 Wood Router Cutting Machines 1530 Machine Tool SpindleWood Router Cutting Machines 1530 Machine Tool Spindle

Popular Products



Wood Router Cutting Machines 1530 Machine Tool Spindle Wood Router Cutting Machines 1530 Machine Tool Spindle Wood Router Cutting Machines 1530 Machine Tool Spindle
Wood Router Cutting Machines 1530 Machine Tool Spindle Wood Router Cutting Machines 1530 Machine Tool Spindle Wood Router Cutting Machines 1530 Machine Tool Spindle



FAQ

Placing order:
If there is not any problem and we agree with each other, then we send to you the PI(proforma invoice)with All the details of machine, both sides sign contract. Then customer make prepayment and send to us the bank receipt pictures.

Strat to produce:
As soon as received your prepayment, we will strat to produce, and inform the news of prodution always,such as pictures, producing videos,testing work etc.
Owning professional testing department, testing precision, real cutting engraving work and every cable connection again, painting etc. before delivery.

Delivery:
After machine finished, we will send detailed pictures and videos to you for confirm, if no problem, will delivery it out and clear Chinese custom

Docusments:
After delivery out, we could prepare all the docusments and send to you, for clear your country custom when machine arrive, such as Bill of Lading, invoice, packing list etc.

Contact us if you need more details on Cutting Machines. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Wood Router、1530 Machine Tool Spindle. If these products fail to match your need, please contact us and we would like to provide relevant information.
